IMC1GSFP60W StarTech.com PoE+ Industrial Fiber to Ethernet Media Converter 60W - SFP to RJ45 - SM/MM Fiber to Gigabit Copper IP-30

General Information

Manufacturer: StarTech.com
Manufacturer Part Number: IMC1GSFP60W
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: Transceiver/Media Converter
Marketing Information: This open SFP PoE fiber media converter offers an easy, inexpensive way to extend the reach of your data and power devices at remote locations using your network over fiber, using the SFP of your choice. It combines the data connectivity of a media converter with the flexible power supply capabilities of a PoE injector

It converts a fiber network link to a PoE-enabled copper RJ45 Ethernet connection to provide data and power to remote PoE devices like security cameras, sensors, wireless, lighting, and more. The converter provides a powerful networking solution for campuses, warehouses, factories or any applications that require PoE and connectivity over long distances.

Designed for Harsh Environments

This 60W media converter can be installed almost anywhere you need it as it has been engineered to work in environments with large temperature changes. The converter also includes a set of DIN mounting rails for additional installation options.

OPERATING TEMPERATURE STORAGE TEMPERATURE
Packaged Quantity: 1 Each
Product Type: Transceiver/Media Converter

Interfaces/Ports

Total Number of Ports: 1
Network (RJ-45): Yes
Number of PoE (RJ-45) Ports: 1

Media & Performance

Media Type Supported: Optical Fiber,Twisted Pair
Fiber Mode Supported: Multi-mode,Single-mode

I/O Expansions

Total Number of Expansion Slots: 1
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1

Network & Communication

Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-T,1000Base-TX,100Base-TX,100Base-T

Power Description

Power Source: PoE+
Power Consumption: 60 W
Plug/Connector Type: Terminal Block (3 Wire),Type N

Physical Characteristics

Form Factor: DIN Rail Mountable,Wall Mountable
Height: 1.30" (33.02 mm)
Width: 3.20" (81.28 mm)
Depth: 4.10" (104.14 mm)
Weight (Approximate): 5.40 oz (153.09 g)

Miscellaneous

Package Contents:

• Transceiver/Media Converter
• Mounting Hardware Kit
• Quick-Start Guide
• Terminal Block to Barrel Power Connector Adapter
• Terminal Block

Environmentally Friendly: Yes
Environmental Certification: EU RoHS
Environmental Compliance: Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE)
Country of Origin: Taiwan

Warranty

Limited Warranty: 2 Year
