ST121SHD50 StarTech.com HDMI Over CAT5e/CAT6 Extender with Power Over Cable - 165 ft (50m)

General Information

Manufacturer: StarTech.com
Manufacturer Part Number: ST121SHD50
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: HDMI Over CAT5/CAT6 Extender with Power Over Cable - 165 ft (50m)
Marketing Information:

The ST121SHD50 HDMI® over Cat5e/Cat6 Video Extender kit lets you extend HDMI video and audio by up to 165 feet (50 Meters) over dual Cat5e cables or dual Cat6 cables.For added versatility the kit features Power Over Cable andonly requires asingle power adapter that can be connected to either the Transmitter or Receiver.

With support for High-Definition resolutions of up to 1920x1080 / 1080p and the accompanying digital audio, this cost-effective HD extender can easily be installed using new or existing Ethernet infrastructure wiring. For a convenient plug-and-play installation, the HDMI extender features built-in EDID monitor emulation, which ensures native resolution and maximum compatibility with your display or projector.

For added flexibility and convenience, HDMI cables up to 32ft (10m) can be connected to both the local and remote units, which lets you extend your HDMI signal to even further distances.

The HDMI extender kit offers a point-to-point digital signage solution rig
Packaged Quantity: 1 Kit
Product Type: Video Extender Transmitter/Receiver

Technical Information

Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 164.04 ft (50000 mm)

Video

Graphics Modes: Full HD
Maximum Video Resolution: 1920 x 1080

Interfaces/Ports

Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
Number of Network (RJ-45) Ports: 4
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1

Media & Performance

Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6

Physical Characteristics

Color Family: Black
Product Color: Black
Transmitter Height: 0.80" (20.32 mm)
Transmitter Width: 2" (50.80 mm)
Transmitter Depth: 3.10" (78.74 mm)
Receiver Height: 0.80" (20.32 mm)
Receiver Width: 2" (50.80 mm)
Receiver Depth: 3.10" (78.74 mm)
Form Factor: Rack-mountable
Transmitter Weight (Approximate): 11.08 oz (314 g)
Receiver Weight (Approximate): 11.08 oz (314 g)

Miscellaneous

Package Contents:

• 1 x HDMI over CAT5e/6 UTP Transmitter
• 1 x HDMI over CAT5e/6 UTP Receiver
• 1 x Universal Power Adapter (NA / EU / UK / AU)
• 2 x Mounting Brackets
• 2 x Foot Pad Set
• 1 x Instruction Manual

Country of Origin: Taiwan
TAA Compliant: Yes
Environmentally Friendly: Yes
Environmental Certification: EU RoHS
Environmental Compliance: Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE)

Warranty

Limited Warranty: 2 Year
