Description
User-Manual
Manufacturer-Brochure
Manufacturer Part Number: 64B1GAR1UZ
Manufacturer Website Address: http://www.lenovo.com/ca/en/
Brand Name: Lenovo
Product Line: ThinkVision
Product Model: P24QD-40
Product Name: ThinkVision P24QD-40 Monitor
Product Type: LED Monitor
Screen Size Class: 24"
Viewable Screen Size: 23.8"
Screen Mode: WQHD
Panel Technology: In-plane Switching (IPS) Technology
Response Time: 4 ms
Response Time Details: 4 ms GTG (Extreme Mode),6 ms GtG Typical
Aspect Ratio: 16:9
Pixel Pitch: 0.20580 mm x 0.20580 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Backlight Technology: WLED
Features: Anti-glare,sRGB,Eyesafe Certified 2.0,Low Blue Light,Flicker-free,Eye Comfort Technology,HDR10,Natural Low Blue Light,Smart Power,Ergonomic Design,Factory Calibration
Vertical Frequency: 48 Hz to 120 Hz
Adjustable Stand: Yes
Stand Adjustments: Swivel,Height,Pivot,Tilt
Active Display Area (H x V): 20.74" (526.80 mm) x 11.67" (296.40 mm)
Standard Refresh Rate: 120 Hz
Color Supported: 16.7 Million Colors
Native Contrast Ratio: 1,500:1
Brightness: 300 cd/m²
Color Gamut: 99% sRGB,99% BT.709
Pixel Per Inch (PPI): 123
HDMI: Yes
USB: Yes
DisplayPort: Yes
USB Type-C: Yes
Total Number of HDMI Ports: 1
Number of DisplayPorts: 2
Number of USB Ports: 7
Number of USB Type-B Upstream Ports: 1
Total Number of USB Type-C Ports: 2
Number of HDMI 2.1 Ports: 1
USB Type-B: Yes
Ethernet Technology Details: 1 x RJ-45 2.5 Gigabit Ethernet
Microphone: No
Maximum Power Consumption: 210 W
Color Family: Black
Product Color: Eclipse Black
Bezel Width: 78.74 mil (2 mm)
Height: 12.43" (315.80 mm)
Width: 21.25" (539.80 mm)
Depth: 1.78" (45.30 mm)
Height with Stand: 19.91" (505.80 mm)
Width with Stand: 21.25" (539.80 mm)
Depth with Stand: 7.48" (190 mm)
Weight (Approximate): 7.94 lb (3600 g)
Weight with Stand (Approximate): 12.35 lb (5600 g)
Compressed Height with Stand: 13.81" (350.80 mm)
Extended Height with Stand: 19.91" (505.80 mm)
Energy Star: Yes
TCO Certified: Yes
Eye Comfort Certification: Yes
Eye Comfort Rating: 5 Star
Environmentally Friendly: Yes
Environmental Certification: TCO Certified 10.0,TCO Certified Edge Displays 2.1,Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Manufacturer-Brochure
General Information
Manufacturer: Lenovo Group LimitedManufacturer Part Number: 64B1GAR1UZ
Manufacturer Website Address: http://www.lenovo.com/ca/en/
Brand Name: Lenovo
Product Line: ThinkVision
Product Model: P24QD-40
Product Name: ThinkVision P24QD-40 Monitor
Product Type: LED Monitor
Technical Information
Number of Screens: 1Screen Size Class: 24"
Viewable Screen Size: 23.8"
Screen Mode: WQHD
Panel Technology: In-plane Switching (IPS) Technology
Response Time: 4 ms
Response Time Details: 4 ms GTG (Extreme Mode),6 ms GtG Typical
Aspect Ratio: 16:9
Pixel Pitch: 0.20580 mm x 0.20580 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Backlight Technology: WLED
Features: Anti-glare,sRGB,Eyesafe Certified 2.0,Low Blue Light,Flicker-free,Eye Comfort Technology,HDR10,Natural Low Blue Light,Smart Power,Ergonomic Design,Factory Calibration
Vertical Frequency: 48 Hz to 120 Hz
Adjustable Stand: Yes
Stand Adjustments: Swivel,Height,Pivot,Tilt
Active Display Area (H x V): 20.74" (526.80 mm) x 11.67" (296.40 mm)
Video
Maximum Resolution: 2560 x 1440Standard Refresh Rate: 120 Hz
Color Supported: 16.7 Million Colors
Native Contrast Ratio: 1,500:1
Brightness: 300 cd/m²
Color Gamut: 99% sRGB,99% BT.709
Pixel Per Inch (PPI): 123
Interfaces/Ports
Network (RJ-45): YesHDMI: Yes
USB: Yes
DisplayPort: Yes
USB Type-C: Yes
Total Number of HDMI Ports: 1
Number of DisplayPorts: 2
Number of USB Ports: 7
Number of USB Type-B Upstream Ports: 1
Total Number of USB Type-C Ports: 2
Number of HDMI 2.1 Ports: 1
USB Type-B: Yes
Ethernet Technology Details: 1 x RJ-45 2.5 Gigabit Ethernet
Built-in Devices
Built-in Devices: USB Hub,KVM SwitchMicrophone: No
Software
Operating System Supported: Windows 10,Windows 11Power Description
Operating Power Consumption: 16.50 WMaximum Power Consumption: 210 W
Physical Characteristics
VESA Mount Compatible: YesColor Family: Black
Product Color: Eclipse Black
Bezel Width: 78.74 mil (2 mm)
Height: 12.43" (315.80 mm)
Width: 21.25" (539.80 mm)
Depth: 1.78" (45.30 mm)
Height with Stand: 19.91" (505.80 mm)
Width with Stand: 21.25" (539.80 mm)
Depth with Stand: 7.48" (190 mm)
Weight (Approximate): 7.94 lb (3600 g)
Weight with Stand (Approximate): 12.35 lb (5600 g)
Compressed Height with Stand: 13.81" (350.80 mm)
Extended Height with Stand: 19.91" (505.80 mm)
Miscellaneous
Package Contents:- ThinkVision P24QD-40 Monitor
- Stand
- 1 x DP 1.4 cable (1.8m)
- 1 x USB-C to USB-C Gen 2 cable (1.5m)
- 1 x USB-B to USB-A Gen 1 cable (1.8m)
- 1 x Power cable (1.8m)
- Factory calibration report
- Quick setup guide
Energy Star: Yes
TCO Certified: Yes
Eye Comfort Certification: Yes
Eye Comfort Rating: 5 Star
Environmentally Friendly: Yes
Environmental Certification: TCO Certified 10.0,TCO Certified Edge Displays 2.1,Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 3 Year
