83KY000PCC Legion 7 16IAX10 4.60 GHz W11H64 32.0GB 1 TB PCIe 16

General Information

Manufacturer: Lenovo Group Limited
Manufacturer Part Number: 83KY000PCC
Manufacturer Website Address: http://www.lenovo.com
Brand Name: Lenovo
Product Line: Legion
Product Series: 7 16IAX10
Product Model: 83KY000PCC
Product Name: Legion 7 16IAX10 83KY000PCC
Marketing Information:

Legion Laptops

Powerful processors, discrete graphics, overlock options, intense lighting effects & more.

Product Type: Gaming Notebook

Technical Information

Release Month: May
Release Year: 2025
AI-powered: Yes

Processor

Processor Manufacturer: Intel
Processor Type: Core Ultra 9
Processor Generation: 2nd Gen
Processor Model: 275HX
Maximum Turbo Speed: 5.40 GHz
Processor Core: Tetracosa-core (24 Core)
Processor Threads: 24
NPU Manufacturer: Intel
NPU Name: AI Boost
NPU Performance: 13 TOPS

Chipset

Chipset Manufacturer: Intel
Chipset Model: HM870

Memory

Total Installed System Memory: 32 GB
Maximum Supported System Memory: 32 GB
System Memory Technology: DDR5 SDRAM
System Memory Speed: 5600 MHz
System Memory Form Factor: SODIMMM
Installed Slot Memory: 32 GB
Installed Slot Memory Configuration: 2 x 16GB
Total Number of Memory Slots: 2
Number of Occupied Memory Slots: 2
Number of Free Memory Slots: 0

Storage

Drive Type: SSD
Total Solid State Drive Capacity: 1 TB
Solid State Drive Interface: PCI Express 4.0
SSD Form Factor: M.2

Display & Graphics

Screen Size: 16"
Screen Mode: WQXGA
Display Screen Type: OLED
Screen Resolution: 2560 x 1600
Brightness: 500 cd/m²
Color Gamut: 100% DCI-P3
Standard Refresh Rate: 240 Hz
Touchscreen: No
Graphics Controller Manufacturer: NVIDIA
Graphics Controller Model: GeForce RTX 5060
Graphics Memory Capacity: 8 GB
Graphics Memory Technology: GDDR7
Graphics Memory Accessibility: Dedicated
AI GPU: Yes
AI TOPS (GPU): 572

Network & Communication

Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11be
Wi-Fi Generation: Wi-Fi 7
Wimax: No
Bluetooth: Yes
WWAN Supported: No

Built-in Devices

Front Camera/Webcam: Yes
Front Camera/Webcam Resolution: 5 Megapixel
Infrared Camera: Yes
Finger Print Reader: No
Sound Mode: Stereo
Speaker Power Details: 2 x 2W

Interfaces/Ports

HDMI: Yes
Total Number of USB Ports: 3
Number of USB 3.2 Gen 1 Type-A Ports: 2
Number of USB 3.2 Gen 2 Type-C Ports: 1
Network (RJ-45): No
Number of Thunderbolt 4 Ports: 1
Docking Capability: USB-C Thunderbolt 4

Operating System

Operating System Platform: Windows
Operating System: Windows 11 Home
Operating System Language: English
Operating System Architecture: 64-bit

Input Devices

Keyboard Localization: English (US)
Keyboard Backlight: Yes

Battery Information

Number of Cells: 4-cell

Power Description

Maximum Power Supply Wattage: 245 W
AC Adapter Frequency: 50 Hz,60 Hz
Included Charger Power: 245 W
USB Power Delivery Support: Yes

Physical Characteristics

Color Family: White
Product Color: Glacier White
Cover Material: Aluminum
Height: 0.70" (17.90 mm)
Width: 14.24" (361.70 mm)
Depth: 10.37" (263.40 mm)

Miscellaneous

Package Contents:

• Legion 7 16IAX10 83KY000PCC
• Standard Battery
• AC Adapter

Charger Included: Yes
Features: Low Blue Light
Energy Efficiency Compliance: Energy-related Products Directive Lot 3 (ErP Lot 3)
Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty: 1 Year
Additional Warranty Information:

1CourierCarryin
