General Information
Manufacturer:
HP Inc.Manufacturer Part Number:
B11W5AT#ABAManufacturer Website Address:
http://www.hp.comBrand Name:
HPProduct Line:
ProProduct Series:
Series 5Product Model:
524daProduct Name:
Series 5 Pro 23.8 inch FHD Monitor - 524daMarketing Information:
Life-like color. Deeper detail.
Upgrade your workday with this vibrant 23.8" FHD monitor. See it all with crystal clear viewing from any angle thanks to IPS technology, 99% sRGB, and a 1500:1 contrast ratio. A 100 Hz refreshrate delivers smooth scrolling and video playback.
Well-crafted to fit any space
This sleek, metal gray monitor is designed to look great in any space. Enjoy crisp audio with dual backfiring 2 W speakers built in, keeping your desk clutter-free. The 3-sided borderless design lets you expand your view seamlessly in a dual-monitor setup.
Elevate your comfort
Designed with you in mind, the 100 mm height- and tilt-adjustable stand and Ergonomic SetupGuide give you customized comfort right at your fingertips. Plus, HP Eye Ease limits blue light to keep your eyes comfortable without impacting color accuracy.
Exactly what you need throughout your day
3-Sided Micro-Edge
Product Type: LED Monitor
Technical Information
Number of Screens: 1
Screen Size Class: 24"
Viewable Screen Size: 23.8"
Screen Mode: Full HD
Panel Technology: In-plane Switching (IPS) Technology
Response Time: 5 ms
Response Time Details: 5 ms GTG (OD)
Aspect Ratio: 16:9
Pixel Pitch: 0.27450 mm x 0.27450 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Backlight Technology: Edge LED
Mount Type: Desk Mountable
HDCP Supported: Yes
Features: OnScreen Control,Security Lock,Low Halogen,OverDrive,Security Lock-ready,Low Blue Light,Anti-glare,Eye Ease,sRGB,Flicker-free
Horizontal Frequency: 30 kHz to 113 kHz
Vertical Frequency: 48 Hz to 100 Hz
Adjustable Stand: Yes
Stand Adjustments: Height,Tilt
Glass Hardness: 3H
Active Display Area (H x V): 20.75" (527 mm) x 11.65" (296 mm)
Video
Maximum Resolution: 1920 x 1080
Standard Refresh Rate: 75 Hz
Native Contrast Ratio: 1,500:1
Dynamic Contrast Ratio: 8,000,000:1
Brightness: 300 cd/m²
Color Gamut: 99% sRGB
Pixel Per Inch (PPI): 93
Native Resolution: 1920 x 1080
Audio
Number of Speakers: 2
Speakers: Yes
Interfaces/Ports
HDMI: Yes
VGA: Yes
Total Number of HDMI Ports: 1
Built-in Devices
Webcam: No
Environmental Conditions
Operating Temperature Range: 41°F (5°C) to 95°F (35°C)
Non-operating Humidity Range: 5% to 95% (Non-condensing)
Power Description
Operating Power Consumption: 21 W
Standby Power Consumption: 500 mW
Maximum Power Consumption: 25 W
Physical Characteristics
Height: 12.43" (315.60 mm)
Width: 21.09" (535.80 mm)
Depth: 1.34" (34 mm)
Height with Stand: 18.10" (459.80 mm)
Width with Stand: 21.09" (535.80 mm)
Depth with Stand: 7.96" (202.20 mm)
Weight (Approximate): 4.89 lb (2220 g)
Weight with Stand (Approximate): 7.76 lb (3520 g)
Miscellaneous
Package Contents: Series 5 Pro 23.8 inch FHD Monitor - 524da HDMI cable Power adapter AC power cord Document kit
Warranty
Limited Warranty: 3 Year
