Description
User-Manual
Manufacturer-Brochure
Manufacturer Part Number: CP550SLG
Manufacturer Website Address: https://www.cyberpowersystems.com/
Brand Name: CyberPower
Product Series: Standby UPS
Product Model: CP550SLG
Product Name: CP550SLG Standby UPS Systems
Marketing Information:
Product Type: Standby UPS
Receptacle Type: NEMA 5-15R
Receptacle Detail: 8 x NEMA 5-15R
Number of Battery & Surge Outlets: 4
Number of Surge-only Outlets: 4
Dataline Protection: RJ-11
Overload Protection: Yes
Cord Length: 5 ft (1.52 m)
Transfer Time: 4 ms
EMI/RFI Noise Filter: Yes
Energy Saving: GreenPower UPS™ High-Efficiency Design
Application/Usage: Desktop Computer,Workstation,Home Theater,Electronic Equipment,Home Network,Router,Modem,VoIP Device
Load Capacity (Watt): 330 W
Input Voltage: 120 V AC
Input Voltage Range: 96 V AC - 140 V AC
Output Voltage: 120 V AC
Input Frequency: 60 Hz
Output Frequency: 50 Hz,60 Hz
Waveform Type: Sine Wave,Simulated Sine Wave
Surge Energy Rating: 890 J
Circuit Breaker: Yes
Output Power Factor: 0.6
USB: Yes
USB (HID Compliant) Port: Yes
Battery Characteristics: Sealed
Battery Chemistry: Lead Acid
Battery Size: 12V
Battery Capacity: 5500 mAh
Backup/Run Time (Full Load): 2 Minute
Backup/Run Time (Half Load): 8 Minute
Typical Battery Recharge Time: 8 Hour
Replaceable Battery: No
Operating Humidity: 0% - 90%
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Height: 5.80" (147.32 mm)
Width: 9.80" (248.92 mm)
Depth: 3.30" (83.82 mm)
Form Factor: Compact
Weight (Approximate): 7.50 lb (3401.94 g)
Software Included: PowerPanel Personal Edition UPS Management Software
Energy Star: No
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Manufacturer-Brochure
General Information
Manufacturer: CyberPower Systems, IncManufacturer Part Number: CP550SLG
Manufacturer Website Address: https://www.cyberpowersystems.com/
Brand Name: CyberPower
Product Series: Standby UPS
Product Model: CP550SLG
Product Name: CP550SLG Standby UPS Systems
Marketing Information:
A compact UPS with standby topology, the CyberPower Standby CP550SLG provides battery backup (using simulated sine wave output) and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. During power interruptions, the CP550SLG offers reliable power protection and battery backup. The CP550SLG comes with a three-year warranty and a
- 100,000 Connected Equipment Guarantee.
Product Type: Standby UPS
Technical Information
Plug/Connector Type: NEMA 5-15PReceptacle Type: NEMA 5-15R
Receptacle Detail: 8 x NEMA 5-15R
Number of Battery & Surge Outlets: 4
Number of Surge-only Outlets: 4
Dataline Protection: RJ-11
Overload Protection: Yes
Cord Length: 5 ft (1.52 m)
Transfer Time: 4 ms
EMI/RFI Noise Filter: Yes
Energy Saving: GreenPower UPS™ High-Efficiency Design
Application/Usage: Desktop Computer,Workstation,Home Theater,Electronic Equipment,Home Network,Router,Modem,VoIP Device
Power Description
Load Capacity (VA): 550 VALoad Capacity (Watt): 330 W
Input Voltage: 120 V AC
Input Voltage Range: 96 V AC - 140 V AC
Output Voltage: 120 V AC
Input Frequency: 60 Hz
Output Frequency: 50 Hz,60 Hz
Waveform Type: Sine Wave,Simulated Sine Wave
Surge Energy Rating: 890 J
Circuit Breaker: Yes
Output Power Factor: 0.6
Management
Alarm: Battery ModeControls/Indicators
Status Indicators: LED Indicators: Power OnInterfaces/Ports
Serial Port: NoUSB: Yes
USB (HID Compliant) Port: Yes
Battery Information
Number of Batteries: 1Battery Characteristics: Sealed
Battery Chemistry: Lead Acid
Battery Size: 12V
Battery Capacity: 5500 mAh
Backup/Run Time (Full Load): 2 Minute
Backup/Run Time (Half Load): 8 Minute
Typical Battery Recharge Time: 8 Hour
Replaceable Battery: No
Environmental Conditions
Storage Temperature: 5°F (-15°C) - 113°F (45°C)Operating Humidity: 0% - 90%
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Physical Characteristics
Product Color: BlackHeight: 5.80" (147.32 mm)
Width: 9.80" (248.92 mm)
Depth: 3.30" (83.82 mm)
Form Factor: Compact
Weight (Approximate): 7.50 lb (3401.94 g)
Miscellaneous
Package Contents:- Standby CP550SLG 550 VA Desktop UPS
- User Manual
- USB A+B Type Cable
- Warranty Registration Card
Software Included: PowerPanel Personal Edition UPS Management Software
Energy Star: No
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 3 Year
