P52560-B21 HPE ProLiant DL380 G11 2U Rack Server - 1 Xeon Silver 4410Y 2 GHz - 32 GB RAM - 12Gb/s SAS Controller

General Information

Manufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: P52560-B21
Manufacturer Website Address: http://www.hpe.com
Brand Name: HPE
Product Line: ProLiant
Product Series: DL380 G11
Product Name: ProLiant DL380 Gen114410Y 2.0GHz 12-core 1P32GB-R MR408i-o NC 8SFF800W PS Server
Marketing Information:

Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen11 delivers world-class performance with the right balance of expandability and scalability. Designed for supreme versatility and resiliency while being backed by a comprehensive warranty make it ideal for multiple environments from Containers to Cloud to Big Data. Standardize on the industry's most trusted compute platform.

Product Type: Server

Processor

Number of Processors Supported: 2
Number of Processors Installed: 1
Processor Type: Xeon Silver
Processor Generation: 4th Gen
Processor Model: 4410Y
Processor Core: Dodeca-core (12 Core)
Processor Speed: 2 GHz
Cache: 30 MB

Chipset

Chipset Manufacturer: Intel

Memory

Standard Memory: 32 GB
Maximum Memory Supported: 8 TB
Memory Technology: DDR5 SDRAM
Memory Clock Speed: 4.80 GHz
Total Number of Memory Slots: 32
Number of Occupied Memory Slots: 1
Signal Processing: Registered (Buffered)

Controllers

Controller Type: 12Gb/s SAS
Controller Model: MR408i-o

I/O Expansions

Number of Total Expansion Bays: 8
Number of Internal 2.5" Bays: 8
Number of SFF Bays: 8
Hot Swappable Bays: Yes
Total Number of Expansion Slots: 3
PCI Express Details: 3-slots (x8, x16, x8) as standard

Network & Communication

Ethernet Technology: Gigabit Ethernet

Interfaces/Ports

Total Number of USB Ports: 4
Number of USB 3.0 Ports: 3
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 1
VGA: Yes
Remote Management: Yes
Remote Management Controller: HPE iLO 6

Operating System

Operating System Supported: Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Oracle Linux

Power Description

Input Voltage: 120 V AC,230 V AC
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 1
Maximum Power Supply Wattage: 800 W
Hot Swappable Power Supply: Yes

Miscellaneous

Package Contents:

• ProLiant DL380 Gen114410Y 2.0GHz 12-core 1P32GB-R MR408i-o NC 8SFF800W PS Server
• SFF Easy Install Rail Kit
• Cable Management Arm

Security Features:

• Secure Boot and Secure Start enable for enhanced security
• Embedded UEFI Shell
• Operating system specific functionality
• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant
• Support for > 2.2 TB (using GPT) boot drives
• PXE boot support for IPv6 networks
• USB 3.0 Stack
• Workload Profiles for simple performance optimization

Environmentally Friendly: Yes
Energy Efficiency Certification: ENERGY STAR 3.0

Physical Characteristics

Form Factor: Rack
Rack Height: 2U
Height: 3.44" (87.50 mm)
Width: 17.64" (448 mm)
Depth: 28.62" (727 mm)
Weight (Approximate): 72.75 lb (33000 g)

Warranty

Limited Warranty: 3 Year
Additional Warranty Information:

3-year parts, 3-year labor, 3-year onsite support with next business day response.
