P55536-001 HPE ProLiant ML110 G11 4.5U Tower Server - 1 Xeon Silver 4410Y 2 GHz - 32 GB RAM - Serial ATA Controller

General Information

Manufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: P55536001
Manufacturer Website Address: http://www.hpe.com
Brand Name: HPE
Product Line: ProLiant
Product Series: ML110 G11
Product Name: ProLiant ML110 Gen11 Server
Marketing Information:

Provide enhanced single processor and storage flexibility in a 4.5U 1P tower optimized server with optional rackable chassis, outstanding compute performance, security, reliability, and expandability at an affordable price. Fill a mid-range of workloads for small offices, remote and branch offices of large enterprises, growing SMBs and data centers with the power of 4th Gen Intel® Xeon® Scalable Processors (up to 32 cores) increased bandwidth with DDR5 and PCIe Gen5. HPE ProLiant ML110 Gen11 server is an excellent choice to accelerate your growing business.

Product Type: Server

Processor

Number of Processors Supported: 1
Number of Processors Installed: 1
Processor Type: Xeon Silver
Processor Generation: 4th Gen
Processor Model: 4410Y
Processor Core: Dodeca-core (12 Core)
Processor Speed: 2 GHz
Cache: 30 MB

Chipset

Chipset Manufacturer: Intel
Chipset Model: C741

Memory

Standard Memory: 32 GB
Maximum Memory Supported: 1 TB
Memory Technology: DDR5 SDRAM
Memory Clock Speed: 4.80 GHz
Error Checking: ECC
Signal Processing: Registered (Buffered)

Controllers

Controller Type: Serial ATA
RAID Supported: Yes

I/O Expansions

Number of Total Expansion Bays: 8
Number of Internal 2.5" Bays: 8
Number of SFF Bays: 8
PCI Express Details: PCIe 5.0: 2 slots (x16), upgradable to 4 slots (x16) OCP 3.0 with PCIe Gen 5.0: 1 slot (x16)

Display & Graphics

Graphics Memory Capacity: 16 MB

Network & Communication

Ethernet Technology: Gigabit Ethernet

Interfaces/Ports

Total Number of USB Ports: 5
Number of USB 2.0 Ports: 1
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
VGA: Yes
Remote Management: Yes
Remote Management Controller: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO Advanced and HPE OneView Advanced (require licenses)

Operating System

Operating System Supported: Windows Server,Red Hat Enterprise Linux,SuSE Linux Enterprise Server,Oracle Linux,Citrix XenServer,Ubuntu

Power Description

Input Voltage: 120 V AC,230 V AC
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 1
Plug/Connector Type: C13/C14
Maximum Power Supply Wattage: 800 W
Hot Swappable Power Supply: Yes

Miscellaneous

Security Features:

• UEFI Secure Boot and Secure Start support
• Immutable Silicon Root of Trust
• FIPS 140-3 validation (iLO 6 certification in progress)
• Common Criteria certification (iLO 6 certification in progress)
• Configurable for PCI DSS compliance
• Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
• Support for Commercial National Security Algorithms (CNSA)
• Tamper-free updates -- components digitally signed and verified
• Secure Recovery -- recover critical firmware to known good state on detection of compromised firmware
• Ability to rollback firmware
• Secure erase of NAND
• TPM (Trusted Platform Module) 2.0
• Front bezel key-lock feature -- standard, available in both Tower and Rack models
• Padlock slot, standard
• Kensington Lock slot, standard
• Chassis Intrusion detection option

Energy Star: Yes
Environmentally Friendly: Yes
Energy Efficiency Compliance: Energy-related Products Directive Lot 9 (ErP Lot 9)
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)

Physical Characteristics

Form Factor: Tower
Rack Height: 4.5U
Height: 18.19" (462 mm)
Width: 7.68" (195 mm)
Depth: 23.11" (587 mm)
Weight (Approximate): 44.31 lb (20100 g)

Warranty

Limited Warranty: 3 Year
Additional Warranty Information:

3-year parts, 3-year labor, 3-year onsite support with next business day response.
