IES5102 StarTech.com 5 Port Industrial Ethernet Switch - DIN Rail Mountable

General Information

Manufacturer: StarTech.com
Manufacturer Part Number: IES5102
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: 5-Port Industrial Ethernet Switch - DIN Rail Mountable
Marketing Information: This compact 5-port industrial Ethernet switch is engineered to deliver fast, reliable network connectivity and durability in the most demanding industrial environments. It provides top performance in a wider range of operating temperatures than conventional network switches, making it ideal for factories and warehouses.
Conquer the tough demands of industrial environments
Designed with a rugged IP30-rated housing, the network switch delivers maximum performance even in harsh industrial conditions. Its wide-range terminal block input gives you the flexibility to power the switch as required, based on your own power input source, while its wide operating temperature range keeps your network running smoothly.
Get up and running in no time
This industrial Ethernet switch is easy to install, with an attached metal bracket for DIN rail mounting on equipment racks and cabinets.
Now you can eliminate the hassle of troubleshooting mismatched speed and duplex settings. This switch gives y
Packaged Quantity: 1 Each
Product Type: Ethernet Switch

Interfaces/Ports

Total Number of Network Ports: 5
Network (RJ-45): Yes
Modular: No
Stack Port: No
Port/Expansion Slot Details: 5 x Fast Ethernet Network

Media & Performance

Media Type Supported: Twisted Pair
Ethernet Technology: Fast Ethernet
Network Technology: 10/100Base-TX

Network & Communication

Layer Supported: 2

Management & Protocols

Manageable: No

Power Description

PoE (RJ-45) Port: No
Power Consumption: 2.12 W

Physical Characteristics

Product Color: Black
Product Material: Plastic
Form Factor: Rail-mountable
Height: 4.30" (109.22 mm)
Width: 1" (25.40 mm)
Length: 2.80" (71.12 mm)
Weight (Approximate): 5.30 oz (150.25 g)

Miscellaneous

Package Contents:

• 5-Port Industrial Ethernet Switch - DIN Rail Mountable
• 1 x Terminal Block
• 1 x Instruction Manual CD

Environmentally Friendly: Yes
Country of Origin: Taiwan
TAA Compliant: Yes

Warranty

Limited Warranty: 2 Year
