MASFP1GBLX10 StarTech.com Cisco Meraki MA-SFP-1GB-LX10 Comp. SFP Module - 1000BASE-LX - 1GbE Gigabit Ethernet SFP Single Mode Fiber SMF Optic Transceiver

StarTech.comSKU: MASFP1GBLX10
No reviews
Price:
$118.99

Description

General Information

Manufacturer: StarTech.com
Manufacturer Part Number: MASFP1GBLX10
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: Cisco Meraki MA-SFP-1GB-LX10 Compatible SFP Transceiver Module - 1000BASE-LX
Marketing Information: The MASFP1GBLX10 is a Cisco Meraki MA-SFP-1GB-LX10 compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 1GbE (100Mbps) connectivity over fiber cable, for 1000Base-LX compliant networks, with a maximum distance of up to 10 km (6.2 mi).
Technical Specifications:
  • Wavelength: 1310nm
  • Maximum Data Transfer Rate: 1.25 Gbps
  • Type: Single Mode Fiber
  • Connection Type: LC Connector
  • Maximum Transfer Distance: 10 km (6.2 mi)
  • MTBF: 3,092,408 hours
  • Power Consumption: Less than 1 Watt
  • Digital Diagnostics Monitoring (DDM): Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warra
Product Type: SFP (mini-GBIC)
Packaged Quantity: 1 Each

Technical Information

Application/Usage: Data Networking,Optical Network

Interfaces/Ports

Total Number of Ports: 1
Connector Type: LC
Interfaces/Ports Details: 1 x LC Duplex 1000Base-LX Network

Media & Performance

Media Type Supported: Optical Fiber
Fiber Mode Supported: Single-mode
Ethernet Technology: 1.25 Gigabit Ethernet
Network Technology: 1000Base-LX

Physical Characteristics

Form Factor: Hot-pluggable,Hot-swappable
Height: 0.50" (12.70 mm)
Width: 5.10" (129.54 mm)
Depth: 2.20" (55.88 mm)
Weight (Approximate): 0.70 oz (19.84 g)

Miscellaneous

Compatibility:
  • MSA Compliant
Cisco Meraki Switches:
  • MS225
  • MX400
  • MS250
  • MS350
  • MX84

Country of Origin: China
Environmentally Friendly: Yes
Environmental Certification: EU RoHS
Environmental Compliance: Restriction of Hazardous Substances (RoHS) 2,Registration, Evaluation, Authorization and Restriction of Chemicals (REACH),Waste Electrical and Electronic Equipment Directive (WEEE)

Warranty

Limited Warranty: Lifetime
