PN-M652 Sharp PN-M652 65" Ultra High-Definition Professional Display

General Information

Manufacturer: Sharp Electronics
Manufacturer Part Number: PN-M652
Manufacturer Website Address: http://www.sharpusa.com
Brand Name: Sharp
Product Line: MultiSync
Product Series: PN-M
Product Model: PN-M652
Product Name: PN-M652 65" Ultra High-Definition Professional Display
Marketing Information:

Masterfully Crafted for Impactful Messaging

The Sharp MultiSync® PN-M Series is your go-to solution for high-impact, ultra-reliable digital signage - designed for demanding environments like healthcare, command centres, finance, retail, and corporate spaces. With factory-calibrated colour accuracy, modular performance options, and a rugged all-metal chassis, these displays bring flawless visuals and pro-grade durability right out of the box.

Product Type: Digital Signage Display

Technical Information

Bezel Width (Top): 0.43" (11 mm)
Bezel Width (Bottom): 0.55" (13.90 mm)
Bezel Width (Left): 0.43" (11 mm)
Bezel Width (Right): 0.43" (11 mm)
Panel Technology: In-plane Switching (IPS) Technology
Operation Hours: 24 Hours/7 Days

Display & Graphics

Number of Screens: 1
Viewable Screen Size: 64.50" (1638.30 mm)
Screen Size Class: 65" (1651 mm)
Display Screen Type: LCD
High Dynamic Range (HDR): Yes
High Dynamic Range (HDR) Type: Hybrid Log Gamma (HLG),HDR10
Response Time: 8 ms
Display Resolution: 3840 x 2160
Orientation: Landscape/Portrait
Backlight Technology: Direct LED
Aspect Ratio: 16:9

Video

Scan Format: 2160p
Native Contrast Ratio: 1,200:1
Brightness: 550 cd/m²
Color Gamut: 72% NTSC

Network & Communication

Ethernet: Yes

Interfaces/Ports

USB: Yes
HDMI: Yes
DisplayPort: Yes
Serial: Yes
Number of HDMI Inputs: 2
Number of HDMI Outputs: 1
Number of DisplayPorts: 3
DisplayPort Output: Yes
RS-232C Input: Yes
Digital Audio Optical Output: Yes
Number of Network (RJ-45) Ports: 2
Number of Audio Line Out: 1
Number of HDMI 2.0 Ports: 2
Number of DisplayPort Outputs: 1

Power Description

Input Voltage: 120 V AC,230 V AC

Physical Characteristics

VESA Mount Standard: 400 x 400
Mount Type: Wall Mountable
Height: 32.77" (832.40 mm)
Width: 57.26" (1454.50 mm)
Depth: 2.34" (59.50 mm)
Weight (Approximate): 57.32 lb (26000 g)

Environmental Conditions

Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 104°F (40°C)
Minimum Operating Humidity: 20%
Maximum Operating Humidity: 80%

Miscellaneous

Package Contents:

• PN-M652 65" Ultra High-Definition Professional Display
• AC Power Cord 3m
• HDMI Cable 2.0m
• IR Remote Control
• Batterie

Application/Usage: Meeting Room,Collaboration,Industrial,Healthcare,Retail,Corporate,Commercial
Energy Star: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Energy Efficiency Certification: ENERGY STAR 8.0

Warranty

Limited Warranty: 3 Year
Additional Warranty Information:

3 years warranty incl. backlight; additional services available; optional 4. + 5. year warranty extension
