SMTL1500RM3UC APC Smart-UPS, Line Interactive, 1500VA, Lithium-ion, Rackmount 3U, 120V, 6x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, Short Depth, AVR, LCD

General Information

Manufacturer: Schneider Electric SA
Manufacturer Part Number: SMTL1500RM3UC
Manufacturer Website Address: http://www.schneider-electric.com
Brand Name: APC by Schneider Electric
Product Line: Smart-UPS
Product Model: SMTL1500RM3UC
Product Name: Smart-UPS Li-Ion, Short Depth 1500VA, 120V with SmartConnect
Marketing Information:

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 1440VA line interactive 3U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6 NEMA 5-15R outlets. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and
Product Type: Line-interactive UPS

Technical Information

Plug/Connector Type: NEMA 5-15P
Receptacle Type: NEMA 5-15P
Receptacle Detail: 6 x NEMA 5-15R
Number of Battery & Surge Outlets: 6
Cord Length: 8 ft (2.44 m)
Transfer Time: 6 ms
Phase: Single Phase
Application/Usage: Server,Router,Network Switch,Network Hub,Network Device

Power Description

Load Capacity (VA): 1.44 kVA
Load Capacity (Watt): 1.35 kW
Input Voltage: 120 V AC
Input Voltage Range: 82 V AC - 144 V AC
Output Voltage: 120 V AC
Waveform Type: Sine Wave
Surge Energy Rating: 680 J

Battery Information

Battery Chemistry: Lithium Ion (Li-Ion)
Backup/Run Time (Full Load): 2.10 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 3 Hour

Physical Characteristics

Product Color: Black,Silver
Height: 5.16" (131 mm)
Width: 17.24" (438 mm)
Depth: 11.89" (302 mm)
Rack Height: 3U
Form Factor: Rack-mountable
Weight (Approximate): 42.99 lb (19499.94 g)

Miscellaneous

Package Contents:

Smart-UPS Li-Ion, Short Depth 1500VA, 120V with SmartConnect

Installation guide

Rack mounting support rails

USB cable

Software Included: Powerchute Serial Edition
Country of Origin: Philippines
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty

Limited Warranty: 5 Year
