ST12MHDLANU StarTech.com HDMI Video and USB over IP Distribution Kit with Video Wall Support - 1080p

General Information

Manufacturer: StarTech.com
Manufacturer Part Number: ST12MHDLANU
Manufacturer Website Address: http://www.startech.com
Brand Name: StarTech.com
Product Name: HDMI and USB over IP Distribution Kit - 1080p
Marketing Information:

This HDMI® over IP kit lets you extend an HDMI signal, as well as four USB peripheral device connections, over your network. You can use additional receivers (sold separately) to distribute the HDMI and USB signals to multiple locations and combine your remote displays to create a video wall while using the USB connection to extend a touch screen to create an interactive digital signage presentation.

Versatile configuration options

In a point-to-multipoint setup, you can connect the HDMI over IP kit through an unmanaged or managed Gigabit LAN portal. You can also connect one or several sources (transmitters) to multiple displays (receivers) over your network, using a managed Gigabit Ethernet switch with IGMP. For further scalability, you can combine up to 16 different extender kits.

For smaller-scale applications, you can use the extender kit as a point-to-point video extender by connecting the transmitter and receiver units directly over Cat5 or Cat6 cabling for a one-to-on
Packaged Quantity: 1 Kit
Product Type: Video Extender Transmitter/Receiver

Technical Information

Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 330 ft (100584 mm)

Video

Graphics Modes: WUXGA
Maximum Video Resolution: 1920 x 1200

Interfaces/Ports

Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 5
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1

Media & Performance

Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6

Physical Characteristics

Color Family: Black
Product Color: Black
Transmitter Height: 1.10" (27.94 mm)
Transmitter Width: 5.20" (132.08 mm)
Transmitter Depth: 5.20" (132.08 mm)
Receiver Height: 1.10" (27.94 mm)
Receiver Width: 5.20" (132.08 mm)
Receiver Depth: 5.20" (132.08 mm)
Transmitter Weight (Approximate): 2.65 lb (1200 g)
Receiver Weight (Approximate): 2.65 lb (1200 g)

Miscellaneous

Package Contents:

• 1 x HDMI over IP transmitter
• 1 x HDMI over IP receiver
• 2 x power adapters
• 2 x screws
• 1 x screw driver
• 2 x CAT5 cables
• 2 x mounting brackets
• 1 x quick install guide

Country of Origin: Taiwan
TAA Compliant: Yes
Environmentally Friendly: Yes

Warranty

Limited Warranty: 2 Year
