TD2350D203 Brother TD-2350D203 Desktop, Retail, Healthcare, Warehouse, Logistic, Manufacturing Direct Thermal Printer - Monochrome - Desktop - Label/Receipt Print - Fast Ethernet - USB - USB Host - Serial - Bluetooth 5.2 - IEEE 802.11a/b/g/n Wireless LAN

General Information

Manufacturer: Brother Industries, Ltd
Manufacturer Part Number: TD2350D203
Manufacturer Website Address: http://www.brother.ca
Brand Name: Brother
Product Series: TD-2D
Product Model: TD-2350D203
Product Name: TD-2350D203 Direct Thermal Printer
Marketing Information:

Increasing productivity and reducing costs are priorities in any workplace. And when it comes to label printing, the TD-2D printers combine proven desktop printer performance with new levels of efficiency to help you do more for less.

With a range of specialised features and print resolution of up to 300dpi, the TD-2D is the perfect label printer for retail, healthcare, warehousing, logistics and manufacturing - plus any other sector where you need to be able to print high-quality receipts or labels at your desk or on the move

Product Type: Direct Thermal Printer

Technical Information

Recommended Use: Label/Receipt Print
Print Color Capability: Monochrome
Maximum Mono Print Speed: 6 in/s (152.40 mm/s)
Maximum Print Resolution (dpi): 203
Maximum Print Length: 118.11" (3000 mm)
Maximum Print Width: 2.32" (59 mm)
Barcode Symbology Supported: Code 39,ITF I-2/5,EAN-8 (JAN8),EAN-13 (JAN13),UPC-A,UPC-E,Codabar (NW-7),Code 128,GS1-128 (UCC/EAN-128),UPC,EAN 2 or 5 Digit Extension,Code 93,POSTNET,MSI,GS1 DataBar,GS1 DataBar (RSS-14),GS1 DataBar Truncated,GS1 DataBar Omnidirectional,GS1 DataBar Limited,RSS14 Limited,RSS Expanded,RSS Expanded Stacked,QR code Model 1,QR Code Model 2,Micro QR Code,Maxi Code,PDF-417,Standard PDF417,Truncated PDF417,Micro PDF-417,Data Matrix ECC Rectangular,Data Matrix ECC Square,AZTEC
Connectivity Technology: Wired & Wireless
Fonts Included: Letter Gothic Regular,Helsinki,Brussels,Gothic,Letter Gothic Bold,Symbol,OCR-A,OCR-B,Utah Condensed Bold
Peel Facility: Yes
Application/Usage: Desktop,Retail,Healthcare,Warehouse,Logistic,Manufacturing
Features: Compact,Easy to Use

Memory

Standard Memory: 256 MB
Flash Memory: 64 MB

Interfaces/Ports

USB Host: Yes
Serial Port: Yes
USB: Yes
USB Standard: USB Type C

Network & Communication

Ethernet: Yes
Ethernet Technology: Fast Ethernet
Bluetooth: Yes
Bluetooth Version: 5.2
Wireless LAN: Yes
Wireless LAN Standard: IEEE 802.11a/b/g/n

Display & Graphics

Display Screen: Yes
Display Screen Type: LCD
Touchscreen: Yes

Media Types & Handling

Media Type: Label,Receipt,Continuous Receipt,Wristband,Continuous Label,Die-cut Label
Maximum Roll Diameter: 5" (127 mm)
Maximum Label Width: 2.48" (63 mm)

Fonts & Emulation

Language Emulation: P-touch Template,ESC/P,Raster,ZPL II,EPL2,DPL,CPCL,ZPL

Software

Operating System Supported:

Linux, Android, IOS, Microsoft Windows 10 / 11, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Microsoft Windows Server 2012

Power Description

Power Source: AC Supply

Environmental Conditions

Operating Temperature: 41°F (5°C) - 104°F (40°C)

Physical Characteristics

Form Factor: Desktop
Height: 6.20" (157.48 mm)
Width: 4.70" (119.38 mm)
Depth: 8.80" (223.52 mm)
Weight (Approximate): 3.37 lb (1528.61 g)

Miscellaneous

Power Adapter Included: Yes
Platform Supported: PC,iOS,Android
