Description
General Information
Manufacturer: Eaton CorporationManufacturer Part Number: SR45UB
Manufacturer Website Address: http://www.eaton.com/EatonCom/Markets/NorthAmerica
Brand Name: Tripp Lite series
Product Line: SmartRack
Product Model: SR45UB
Product Name: 45U SmartRack Premium Enclosure (Includes Doors and Side Panels)
Marketing Information: The SR45UB features a massive front-to-rear ventilation capacity that meets or exceeds server manufacturer requirements. Its integrated baying tabs make it easy to combine multiple enclosures in rows for data center applications. This enclosure is also compatible with hot-aisle/cold-aisle configurations.
The SR45UB houses 3,000 pounds (1360.8 kilograms) of standard 19-inch rack equipment in 45U. Its front and rear pairs of vertical rails have square mounting holes that are adjustable in quarter-inch increments from four to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.
Two of the adjustable vertical mounting rails support toolless button-mount 0U installation of up to four compatible PDUs and cable managers. This feature makes it easier to route cabling to rack equipment and reduces cord clutter.
With its locking, reversible, removabl
Product Type: Rack Cabinet
Physical Characteristics
Color Family: BlackProduct Color: Black
Dynamic/Rolling Weight Capacity: 2250 lb (1020582.83 g)
Static/Stationary Weight Capacity: 3000 lb (1360777.11 g)
Height: 83.75" (2127.25 mm)
Width: 23.63" (600.20 mm)
Depth: 43" (1092.20 mm)
Rack Height: 45U
Rack Width: 19" (482.60 mm)
Weight (Approximate): 307 lb (139252.86 g)
Miscellaneous
Package Contents:- 45U SmartRack Premium Enclosure (Includes Doors and Side Panels)
- 4 x Side Panels
- 4 x Side Panel Locks
- 50 x M6 Screws
- 50 x M6 Cage Nuts
- 50 x M6 Washers
- 2 x Door and Side Panel Keys
- Owner's Manual
- Stabilizer Plate
- Mounting Hardware Kit
- Baying Hardware Kit
Assembly Required: No
Country of Origin: China
Environmentally Friendly: Yes
Environmental Compliance: Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty: 5 Year
